| Engine Family | Modular 5.0 "Coyote" 4 Valve |
|---|---|
| CID/Ltr | 302/4.9 |
| Bore Inch | 3.631 |
| Bore mm | 92.23 |
| Stroke Inch | 3.65 |
| Stoke mm | 92.71 |
| Rod Length | 5.933 |
| Comp Dist | 1.166 |
| Crown Volume | -16cc |
| CR 1 | |
| CR 2 | 9.9 @ 57cc |
| CR 3 | |
| Alloy | 2618 |
| Weight | Call |
| Pin | 0.866 |
| Oil Rails Included | N/A |
| Top Ring | 1.5mm |
| 2nd Ring | 1.5mm |
| Oil Ring HT | 3.0mm |
| Piston Style | Dish |
RaceTec, Modular 5.0 "Coyote" 4 Value, Dish, 3.631 Bore 3.650 Stroke 1.166 Comp HT
Need Tech Help? Call 714-903-4362
